RJ/ TRANSFORMER SOCKET RJ/ Transformer 插座

RJ45-8305 SATA+USB2.0
RJ45 network interface series

RJ45-8305 SATA+USB2.0

RJ45網絡接口 FEATURE ‧17.30mm*20.10mm ‧SATA+USB2.0 APPLICATIONS ‧ LCD TV, router, switch, tablet PC, projector


產品說明

COMMON SPECIFICATIONS

CharacteristicsSpecification
額定電壓/Rated voltage125VAC RMS
電流/Current1.5AMP
接觸電阻/Contact resistance35MILLIOHMS MAX
絕緣電阻/Insulation resistance

USB:1000M ohm MIN

SATA:100M ohm MIN

介電強度/Dielectric strength

USB:750VAC RMS 50HZ 1MIN

SATA:500VAC RMS 50HZ 1MIN


DIMENSIONS

Unit:mm

ModelDimensions

RJ45-8305 SATA+USB2.0RJ45-8305 SATA+USB2.0

RJ45-8305 SATA+USB2.0
